Model NO. | agrotianda504 | Type | Wheel Tractor |
Usage | Farm Tractor, Garden Tractor | Certification | ISO, SGS |
Drive Wheel | 4WD | Emission Standard | Euro II |
Fuel | Gas / Diesel | Service Life | 6-10 Years |
Size | Small | Color | Blue |
Condition | New | Power | 50HP |
Engine Brand | 4 Cylinder, Diesel, Vertical, Water Cooling | Weight | 1600kg |
Transport Package | Nude Packing | Specification | 4000 x 1600 x 2400mm |
Trademark | Agrotianda | Origin | China |
HS Code | 8701901190 | Production Capacity | 10000unit/Year |
Specification for agrotianda Tractor | ||||||
Model | TE-504 | TB-754 | TB-904 | 4X-1004 | TD-1204 | TD-1404 |
Engne Model | XINCHA | XINCHAI | XINCHAI | QUANCHAI | SHANG CHAI | SHANG CHAI |
Type | 4-Cylinder Vertical,water cooled,4 stroke cycle | 6-Cylinder Vertical,water cooled,4 stroke cycle | ||||
Construction Mass(kg) | 1800 | 2900 | 2900 | 3700 | 3900 | 3900 |
Wheel Bass(mm) | 1800 | 2010 | 2052 | 2052 | 2340 | 2340 |
Min Ground Clearance (mm) | 308 | 308 | 375 | 375 | 400 | 400 |
Rated Power(kw/hp) | 36.7/50 | 55.1/75 | 66.2/90 | 73.5/100 | 88.2/120 | 102.9/140 |
Rated Speed (rpm) | 2400 | 2400 | 2400 | 2400 | 2400 | 2200 |
Gear box | 8+8 | 12+12 | 12+12 | 12+12 | 12+12 | 16+8 |
Brake | Disc type | Disc type | Disc type | Disc type | Disc type | Disc type |
3-Point Suspension | Category:3 | Category:3 | Category:3 | Category:3 | Category:3 | Category:3 |
Rotating Speed (rpm) | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 | 540/1000 |
Production Process and Flow
Packaging and Shipping
OEM/ODM Customization Available
Color | Blue, yellow, red, orange, green, and any custom color of your choice. |
Engine Brand | Quanchai,Xinchai,Yuchai,YTO,Shangchai,Yunei |
Rated Power (hp) | 50-240hp |
Tire Tape | Dryland, Paddy Field, Radial (European Standard)—customizable upon request. |
Logo | Your exclusive logo can be applied to the tractor body or hood. |
1. Exceptional Power & Efficiency
Engineered for Performance: Equipped with a high-torque, low-fuel-consumption diesel engine (matching brands like YTO/Quanchai), ensuring powerful output for heavy-duty plowing, tilling, and hauling.
Optimized Transmission: The 8+2 or 12+12 shuttle shift transmission provides versatile speed options, allowing operators to match the perfect pace for different soil conditions and implements.
2. Superior 4WD Traction & Stability
All-Terrain Mastery: The robust 4-Wheel Drive (4WD) system delivers maximum traction on muddy, hilly, or uneven terrains, significantly reducing wheel slippage and increasing productivity.
High Ground Clearance: Designed specifically for rugged environments, the chassis offers excellent clearance to protect the underbody while navigating deep furrows or obstacles.
3. Built for Durability
Heavy-Duty Chassis: Reinforced structural components ensure the tractor can withstand the rigors of long-term, high-intensity field operations.
Reliable Hydraulic System: Features a dual-way hydraulic output, making it compatible with a wide range of implements (plows, trailers, seeders, etc.) with smooth and precise control.
4. Operator-Centric Design
Ergonomic Cabin: Available with a comfortable, wide-view cabin or a foldable ROPS (Roll-Over Protective Structure). The intuitive layout of controls reduces operator fatigue during long working hours.
Power Steering: Standard hydraulic power steering ensures effortless maneuverability, even in tight spaces or with heavy front-end attachments.
5. Low Maintenance & High ROI
Easy Access Service Points: The streamlined hood design allows for quick access to the engine, filters, and battery, simplifying daily maintenance and reducing downtime.
Cost-Effective Operations: Optimized for fuel efficiency and built with standardized components, ensuring that your long-term operational and spare parts costs remain low.
